- Place of Origin: Shandong, China
- Brand Name: LuYoung
- Model Number: CK6132
- Weight: 900.000 kg
Specification:
Item | CK6132 |
Max. swing dia. over bed | 360mm |
Max. swing dia. over cross slide | 150mm |
Max. processing length | 450mm |
Dia. of spindle | 40mm |
Spindle taper | MT5 |
Spindle speed | 150-2500mm |
Tool holder | 4 station or gang tool |
Tool bar section | 20X20 mm |
Main motor power | 4kw |
X/Z axis travel/ stoke | 310/450 |
X/Z axis fast feeding speed | 6/8 M/MIN |
Tailstock sleeve travel | 100mm |
Tailstock taper | MT3 |
Dimension | 1820mm×1100 mm×1550mm |
weight | 1200kg |
Standard configuration:
ü GSK 928TD-L
ü Manual 3 jaw chuck
ü 4 station tools carrier
ü Auto lubrication system
ü Lighting system
ü Cooling system
ü 380V 3 phase(if your local have special request pls let us know)
Option configuration:
ü 6 /8 station electrice tool holder
ü Auto feeder system
ü Pneumatic chuck
ü Hydrualic chuck
Company Overview
Taian Lu Young Machinery Co., Ltd., is a modern and high- tech company which is a professional manufacturer of CNC LATHE, CNC MILLING, CNC MACHINE CENTER . With 5,000sqm workshops and offices, we have more than 20 years experiences in cnc machine research and production.Our machines have been exported more than 40 countries.we welcome all customers and friends to come to our company!
Regarding the technical force, we have the most professional research and development staff, who can meet all different requirements on technology and production.
For the sales, there are internal trade department and international trade department. They are all professional salespersons who can help you solve problems on purchase and technology related to the CNC tools and test machines. Our products are sold both at home and abroad, and they are very popular around the world. All of products have pass CE certification.Welcome to contact with us to make building!!
