- Place of Origin: Shandong, China
- Brand Name: LuYoung
- Model Number: CK6432
- Weight: 1200.000 kg
Quick Details
Condition: New
Type: Horizontal
CNC or Not: CNC
Automatic Grade: Automatic
Max. Swing Diameter: 360mm
Place of Origin: Shandong, China (Mainland)
Brand Name: Lu Young
Model Number: CK6432A
Voltage: 380V
Power(W): 4KW
Dimension(L*W*H): 1660X1400X1700mm
Weight: 1200kg
Certification: CE Certificate
After-sales Service Provided: Engineers available to service machinery overseas
Machine Type: Cheap Small CNC Lathe Price for Sale from China
Spindle bore: 60mm
Spindle speed: 150-2500rpm
Processing length: 450mm/700mm
Tool holder: 4station electric tool holder
Tailstock sleeve travel: 100mm
tailstock taper: MT4
Chuck: Manual 3 jaw chuck
System: GSK FANUC SIEMENS
Warranty: 12MONTHS
Packaging & Delivery
| Packaging Details: | Standard export package for Cheap Small CNC Lathe Price for Sale from China |
|---|
| Delivery Detail: | Shipped in 15 days after payment |
|---|
Product Description
| Specification for Small CNC Lathe Machine CK6432 |
| Item | CK6432 |
| Max. swing dia. over bed | 360mm |
| Max. swing dia. over cross slide | 150mm |
| Max. processing length(mm) | 450 | 700 |
| Dia. of spindle hole | 60mm |
| Spindle speed | 150-2500rpm |
| spindle taper | MT6 |
| Tool holder | 4 station electric tool post(optional 6/8staion electric turret) |
| Tool bar section | 20x20 |
| Main motor power | 4kw |
| X/Z axis fast feeding speed | 8/10 m/min |
| X/Z axis position accuracy(mm) | 0.01/0.015 |
| X/Z-axis repeatability(mm) | 0.012/0.013 |
| Clamping | 3 Jaw Manual Chuck(optional pnematic or hydraulic chuck) |
| Tailstock sleeve dia. | 60 |
| Tailstock sleeve travel | 100mm |
| Tailstock taper | MT4 |
| Dimension | 1660X1400x1700 |
| 1940x1400x1700 |
|
|
| Weight(kg) | 1250 | 1450 |
| Standard configuration: | Optinal configuration: |
| GSK928 CNC Controller | Siemens,Fanuc cnc controller system |
| Servo motor for X,Z axis, Servo driven | pneumatic chuck,hydraulic chuck |
| 3 Jaw Manual Chuck | pneumatic tailstock,hydraulic tailstock |
| 4 station electric tool post | 6 staion tool turret,8staiton tool turret |
| Auto lubrication system | Auto feeder system |
| lighting system | Chip conveyor |
| cooling system |
|
